HyperCAD-S, the CAD element within the hyperMILL suite, also offers new features. In addition to this, all movements are checked for collisions on both 3- and 5-axis machine tools." "This new addition makes it possible to quickly and reliably define the component zero-point, providing more precise and efficient machining. "This benefit is complemented by the new Zero-Point Definition tool," said the spokesperson. Deviations in dimensional accuracy can be processed in the controller for actual machining based on the offset value. The Active Process Control feature allows probing cycles to be integrated into the machining process in order to actively control parameters.
HYPERMILL 2015.1 PLUS
With the Informative Process Control feature, it is possible to create measuring data for the individual component geometries and access it from the controller, a major plus for any machine shop." "Enabling users to choose between three measuring functions, the Informative Process Control, Active Process Control and Zero-Point Definition, OPEN MIND will improve process reliability for customers. "The touch probe is easy to program in all cycles, just like a tool in hyperMILL," said the spokesperson. These include the measurement of rectangle and circle elements as well as measuring parallel to the axis.
Three new probing cycles are featured in hyperMILL 2015.1. Particularly suited to difficult-to-cut materials, this strategy improves cycle times and tool life considerably." By setting the milling tool inclination based on 5- axes, the user can benefit from efficient and tool-friendly machining with rapid swarf removal. This helical drilling cycle generates helical tool paths with the tool plunging into the material quickly, eliminating the need for predrilling operations. "The most important expansion in hyperMILL 2015.1 is a 5-axis helical drilling strategy. Numerous extensions in hyperCAD-S, the CAD system for CAM users, also offers added value. These features can considerably reduce programming times and enable efficient machining. "There are five highlights in the latest package that include new functions for 2-D and 5-axis machining. "The latest version of OPEN MIND's CAM/CAD suite hyperMILL will include many new optimizations, machining strategies and intuitive features that can further utilize the possibilities of modern CNC machines while enhancing ease of use," said a company spokesperson. Southeast Manufacturing News - October 2015 New Version Of CAM/CAD Suite Includes Functions For 2-D, 5-Axis Machining
